Magnet Filter Reearth [RE]
-
High magnetic force MAGNETIC TYPE FILTER "RE-EARTH" conveyor has been developed& designed a filtration device by MOSNIC.This model is high grade than ever before magnetic conveyor one. We called "ONE-PASS" method filter which has function of primary and secondary filtration is unique structure. Not only CUTTING PROCESS but also GRINDING PROCESS are capable to select.
-
Features
- High-precision filtration is achieved by fusing the floor magnet (ferrite)method and the magnet separator (rare earth) method.
- * Rare earth = rare earth
- Magnetic floor at conveyor bottom has been integrated magnetic separator. High-level- clarity is achieved by ferrous magnet and rare-earth magnet joined one conveyor. Floating fine sludge having difficulty precipitation and adsorption by magnetic flor and floating super-fine-sludge on the liquid surface can be caught at the same time.
- Reduction of primary tank cleaning ( reducing 1/100, comparing at MOSNIC TEST of sediment of sludge)
- Because of pump less for secondary filter, it makes initial cost, running cost, CO2 and maintenance frequency reduced.
- One drive motor can be for conveyor device.
- Filter Rating : 90% and 10～20μm over
Main Specifications
We can also customize a product to satisfy your needs. All inquiries are welcome.
RE
Basic Specification
| Filter Rating | 50μm·90% 30μm·90% 20μm·90% 10μm·90% |
|---|---|
| Filter Volume (liters/min) |
～500 ～1,000 ～2,000 ～3,000 ～3,500 ～6,000 |
| Coolant | Water soluble Oils |
Applicable Chip Shape Table
| Material | Shape | ||||
| Cutting | Polishing | Washing | |||
| Non Magnetic Materials |
50mm or Longer
50mm or shorter
Needle-Shaped
Floating Chips
After Primary Stage
|
Sludge | Grains | ||
|---|---|---|---|---|---|
| Magnetic Particles (Steel) |
50mm or Longer
50mm or shorter
Needle-Shaped
Floating Chips
After Primary Stage
|
Sludge | Grains | ||
| Magnetic Particles (FC) |
50mm or Longer
50mm or shorter
Needle-Shaped
Floating Chips
After Primary Stage
|
Sludge | Grains | ||
